| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 0918506781358U |
| Series: | SEK |
| Gender: | Female |
| Housing Material: | Plastic |
| Number of Contacts: | 6 |
| Number of Rows: | 2 |
| Termination Method: | IDC |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 1.27 mm, 2.54 mm |
| Housing Color: | Gray |
| Mating Cycles: | 50 cycle |
| Wire Size: | 28 - 26 AWG |
| Performance Level: | Class III |
| Current Rating: | 2.5 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT0918506781358U |
0918506781358U
Specifications
Detailed Description
Introducing the SEK-18 SV FE TYPA ZGL 06P PL3, a high-performance IDC ribbon cable connector designed for female gender applications. Constructed with durable plastic housing in a sleek gray color, this connector features 6 contacts arranged in 2 rows, with a pitch of 2.54mm or 1.27mm for versatile connectivity. The contacts are made of copper alloy with tin over nickel and noble metal plating, ensuring reliable signal transmission even in harsh environments with a wide operating temperature range from -55°C to 125°C. With a current rating of 2.5A and voltage rating of 1kV, this connector is suitable for various power and signal applications. Meeting Class III performance levels and rated for 50 mating cycles, it guarantees long-lasting durability. Compatible with wire sizes ranging from 28 to 26 AWG, it offers flexibility in installation. Ideal for use in demanding industrial and commercial settings, this connector is a dependable solution for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
