| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185105329 |
| Color: | Gray |
| Series: | SEK Low-profile |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 10 |
| Number of Rows: | 2 |
| Termination Method: | Press-Fit |
| Contact Material: | Copper Alloy |
| Contact Plating: | Nickel, Noble Metal Over Nickel |
| Maximum Operating Temperature: | 105 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 5.5 mm |
| Mating Cycles: | 250 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185105329 |
09185105329
Specifications
Detailed Description
SEK Low-profile Connector is a reliable solution for connecting PCB to cable with ease. Featuring a male connector made of durable thermoplastic resin (PBT) in a sleek beige hue, it offers a secure press-in termination method. With a high contact count of 10, this connector ensures efficient signal transmission. Its copper alloy contacts with nickel plating guarantee excellent conductivity, while the noble metal over nickel plating enhances durability. Operating within a wide temperature range from -55°C to 105°C, it is suitable for diverse environments. With an IP20 rating for protection against solids, this connector is ideal for various applications. Meeting UL 94V-0 flammability standards, it ensures safety. Boasting a current rating of 1A and voltage rating of 1 kV, this connector is both reliable and efficient. Perfect for board to board connections, it is a valuable component in any electronic setup.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
