| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185146024 |
| Color: | Gray |
| Series: | SEK Standard |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 14 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Mating Cycles: | 250 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 500 V |
| SKU: | HRT09185146024 |
09185146024
Specifications
Detailed Description
SEK Standard Male Connector is designed for reliable PCB to cable connections in electronic applications. With a housing made of durable thermoplastic resin (PBT) in a sleek beige color, this connector offers a secure and efficient solution. Featuring 14 contacts in 2 rows, it ensures seamless signal transmission. The wave soldering termination method guarantees easy installation on the PCB. Rated for a current of 1A and a voltage of 500V, it meets high-performance requirements. With a wide operating temperature range of -55°C to 125°C and a flammability rating of UL 94V-0, it ensures safety and reliability in any environment. RoHS compliant and with a contact plating of Tin Over Nickel, Noble Metal Over Nickel, it also meets environmental standards. Perfect for Board To Board PCB Connections, the SEK Standard Male Connector is a top choice for engineers and designers seeking quality and performance in their projects.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
