| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185147913 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 14 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185147913 |
09185147913
Specifications
Detailed Description
The SEK Standard Male Connector ( 09185147913) is a reliable and durable component for PCB to cable connections. Made of high-quality thermoplastic resin (PBT) in a sleek beige finish, this connector is designed for wave soldering termination with 14 copper alloy contacts plated with tin over nickel, ensuring optimal conductivity. With a rated current of 1A and a voltage rating of 1 kV, it guarantees safe and efficient performance. Operating in temperatures ranging from -55°C to 125°C, it is suitable for a wide range of applications. Its IP20 rating and UL 94V-0 flammability rating make it ideal for use in various environments. Featuring a right-angle mount and a pitch of 2.54mm, it offers easy installation and compatibility with standard PCB layouts. ROHS compliant and offering high reliability, this connector is a perfect choice for demanding electronic systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
