| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185147922 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 14 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 4.5 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185147922 |
09185147922
Specifications
Detailed Description
The SEK Standard Male Connector ( 09185147922) is a reliable and efficient component for your electronic assembly needs. Made of high-quality thermoplastic resin (PBT) in a sleek beige finish, this connector ensures durability and performance. With 14 contacts and a PCB to cable connection, it facilitates seamless data and power transfer. The wave soldering termination method guarantees secure attachment, while the copper alloy contacts with tin over nickel plating offer excellent conductivity. Operating within a wide temperature range (-55°C to 125°C) and rated for 1A current and 1kV voltage, it is suitable for diverse applications. With a pitch of 2.54mm, IP20 rating, straight mount angle, and UL 94V-0 flammability rating, it meets industry standards for safety and reliability. Trust the SEK Standard Male Connector for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
