| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185167924 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 16 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185167924 |
09185167924
Specifications
Detailed Description
Introducing the SEK Standard Male Connector, a high-quality component designed for seamless PCB to cable connections. Made from durable thermoplastic resin (PBT) in a sleek beige finish, this connector features wave soldering termination for easy installation. With a rated current of 1A and 16 contacts, it guarantees reliable performance in various applications. Crafted with precision, the copper alloy contacts are plated with tin over nickel and noble metal for optimal conductivity. Operating temperature ranges from -55°C to 125°C, ensuring versatility in harsh environments. Its straight mount angle and 2.54mm pitch make it suitable for standard PCB setups. UL 94V-0 rated for flammability, it offers peace of mind in terms of safety. Perfect for use in electronics manufacturing, the SEK Male Connector is a dependable choice for professionals seeking top-tier connectivity solutions.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
