| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185266924 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 26 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185266924 |
09185266924
Specifications
Detailed Description
SEK Standard Connector, SKU 09185266924, offers reliable connectivity for PCB to cable applications. This male connector, made of beige thermoplastic resin (PBT), features 26 contacts for seamless data transmission. With a wave soldering termination method, it ensures secure attachment to the PCB. Rated for 1A current, it guarantees efficient power delivery. The connector's durable construction, with a plastic housing and copper alloy contacts plated with tin over nickel, meets high industry standards. Operating within a wide temperature range from -55°C to 125°C, it is suitable for diverse environments. With an IP20 rating, it provides protection against dust and moisture. RoHS compliant and boasting a flammability rating of UL 94V-0, it prioritizes safety and environmental responsibility. Suitable for various electronic applications, this connector is a dependable choice for demanding projects.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
