| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185267922 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 26 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 4.5 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185267922 |
09185267922
Specifications
Detailed Description
Introducing the SEK Standard Male Connector, designed for seamless PCB to cable connections. Crafted with durable thermoplastic resin (PBT) in a sleek beige finish, this connector boasts a robust construction suitable for wave soldering termination. With a high contact count of 26, it ensures reliable signal transmission. The contacts, made of copper alloy and plated with tin over nickel and noble metal over nickel, guarantee excellent conductivity and corrosion resistance. Operating flawlessly in temperatures ranging from -55 °C to 125 °C, it's suitable for a wide range of applications. With a current rating of 1A and voltage rating of 1kV, it meets industry standards for performance and safety. The SEK Standard Male Connector is the perfect choice for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
