| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185345324 |
| Color: | Gray |
| Series: | SEK Low-profile |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 34 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Mating Cycles: | 250 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185345324 |
09185345324
Specifications
Detailed Description
SEK Low-profile Connector is a reliable solution for seamless PCB to cable connections. Designed for male connectors, it features a durable thermoplastic resin housing in a sleek beige finish. With 34 contacts arranged in two rows, this connector ensures efficient signal transmission. The wave soldering termination method guarantees secure attachment to PCBs. Rated for a maximum current of 1A and a voltage of 1kV, it operates effectively in a wide temperature range from -55°C to 125°C. With a pitch of 2.54mm and a straight mount angle, it offers easy installation. ROHS compliant and with a flammability rating of UL 94V-0, this connector meets stringent industry standards for safety and environmental responsibility. Perfect for high-performance applications, the SEK Connector is a vital component for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
