| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185605921 |
| Color: | Gray |
| Pitch: | 2.54 mm |
| Series: | SEK Standard |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 4.5 mm |
| Current Rating: | 1 A |
| Number of Rows: | 2 |
| Voltage Rating: | 1 kV |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Plastic |
| Number of Contacts: | 60 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT09185605921 |
09185605921
Specifications
Detailed Description
The SEK Standard Connector, SKU 09185605921, is a versatile male connector designed for efficient PCB-to-cable connections. Constructed with durable beige thermoplastic resin (PBT) housing, this connector offers reliable performance in a wide range of environments. With a wave soldering termination method and 60 contacts, it ensures secure and stable connectivity. Rated for a current of 1A and featuring copper alloy contacts with tin over nickel plating, it guarantees excellent conductivity. Operating in temperatures ranging from -55°C to 125°C, it is suitable for various applications. The right-angle mount and 2.54mm pitch make it easy to integrate into existing setups. With a flammability rating of UL 94V-0 and IP20 protection, it prioritizes safety. Ideal for use in hi-rel environments, this connector is a dependable solution for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
