| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185646921 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 64 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 4.5 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185646921 |
09185646921
Specifications
Detailed Description
The SEK Standard Male Connector, SKU 09185646921, offers reliable connectivity in electronic assemblies. Made of durable beige thermoplastic resin (PBT) with a high flammability rating of UL 94V-0, this connector is suitable for PCB to cable connections. It features 64 contacts, each plated with Tin over Nickel for enhanced conductivity. With a rated current of 1A and a voltage rating of 1kV, it ensures efficient power transmission. Operating in temperatures ranging from -55°C to 125°C, it is ideal for various environments. The right angle mount and wave soldering termination method make installation easy and secure. 2.54mm pitch and IP20 rating further enhance its versatility, making it a reliable choice for demanding applications in industries such as aerospace, automotive, and telecommunications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
