| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185646923 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 64 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185646923 |
09185646923
Specifications
Detailed Description
SEK Standard Connector, SKU 09185646923, is a reliable and efficient solution for PCB to cable connections. This male connector features a durable thermoplastic resin (PBT) construction in a sleek beige color, ensuring longevity and performance. With wave soldering termination, installation is a breeze. Boasting 64 contacts, each plated with tin over nickel for optimal conductivity, this connector guarantees a secure and stable connection. Operating between -55°C to 125°C, it is suitable for a wide range of environments. Rated for 1A current and 1kV voltage, it meets high standards of performance and safety. With a pitch of 2.54mm and right-angle mount, it offers versatility in application. UL 94V-0 rated for flammability, it ensures peace of mind in use. Trust the SEK Standard Connector for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
