| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09195107324 |
| Color: | Beige |
| Series: | SEK Low-profile |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 10 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Mating Cycles: | 50 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09195107324 |
09195107324
Specifications
Detailed Description
SEK Low-profile Connector, SKU 09195107324, is a reliable and efficient solution for connecting PCBs to cables. Featuring a male connector with 10 contacts in 2 rows, this beige connector is made of thermoplastic resin (PCT) for durability. With reflow soldering termination (THR/SMC) method, it ensures secure and stable connections. Rated for 1A current and 1kV voltage, it operates in a wide temperature range from -55°C to 125°C. The copper alloy contacts with tin over nickel plating guarantee excellent conductivity. With a pitch of 2.54mm and straight mount angle, it allows for easy and convenient installation. Meeting IP20 ingress protection and UL 94V-0 flammability rating, it ensures safety and reliability in various applications. The SEK connector is ideal for use in hi-rel environments and is designed for 50 mating cycles, making it a dependable choice for board to board PCB connections.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
