09195166903

HRT09195166903
Heilind Number:HRT09195166903
Manufacturer:HARTING
Manufacturer Number:09195166903
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

SEK, Standard, Connector; Male connector; Thermoplastic resin (PCT), Beige; PCB to cable; Reflow soldering termination (THR/SMC); Rated current: 1A

More >>

Specifications

AttributeValue
Product Category:
Board To Board PCB Connectors Mezzanine & Board Stacking Connectors
Manufacturer:HARTING
Manufacturer Part Number:HARTING 09195166903
Color:Beige
Pitch:2.54 mm
Gender:Male
Series:SEK Standard
Mount Angle:Right Angle
Tail Length:2.9 mm
Mating Cycles:250 cycle
Current Rating:1 A
Number of Rows:2
Voltage Rating:500 V
Contact Plating:Noble Metal Over Nickel, Tin Over Nickel
Contact Material:Copper Alloy
Housing Material:Plastic
Number of Contacts:16
Termination Method:Solder
Flammability Rating:UL 94V-0
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-55 °C
Part Aliases:
SKU:HRT09195166903

Detailed Description

SEK Standard Connector is a reliable and efficient solution for PCB to cable connections. With a male gender, it features a durable thermoplastic resin (PCT) housing in a sleek beige color. The 16 contacts arranged in 2 rows ensure secure and stable connectivity. Utilizing reflow soldering termination (THR/SMC), it guarantees hassle-free installation. With a high current rating of 1A and voltage rating of 500V, it meets the demands of various applications. The contact material of copper alloy with tin over nickel plating ensures excellent conductivity. Operating in temperatures ranging from -55°C to 125°C, it is suitable for diverse environments. UL 94V-0 flammability rating provides added safety. Perfect for board to board PCB connections, it offers 250 mating cycles, ensuring long-term performance. Trust in the SEK Standard Connector for seamless and durable connectivity.
