| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09195207324 |
| Color: | Beige |
| Pitch: | 2.54 mm |
| Gender: | Male |
| Series: | SEK Low-profile |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Mating Cycles: | 50 cycle |
| Current Rating: | 1 A |
| Number of Rows: | 2 |
| Voltage Rating: | 1 kV |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Plastic |
| Number of Contacts: | 20 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT09195207324 |
09195207324
Specifications
Detailed Description
SEK Low-profile Connector ( 09195207324) is a male connector designed for seamless PCB to cable connections. Crafted from durable thermoplastic resin (PCT) in a sleek beige hue, this connector ensures reliable performance in a variety of applications. With 20 contacts arranged in 2 rows and a pitch of 2.54mm, it offers efficient connectivity. The reflow soldering termination (THR/SMC) method guarantees secure attachment, while the copper alloy contacts with tin over nickel plating ensure optimal conductivity. Rated for a current of 1A and a voltage of 1kV, this connector operates flawlessly in temperatures ranging from -55°C to 125°C. With an IP20 rating for dust and moisture protection, along with UL 94V-0 flammability rating, it prioritizes safety. Suitable for 50 mating cycles, it is ideal for use in high-demand environments. Upgrade your connectivity solutions with the SEK Low-profile Connector.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
