| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09195245924 |
| Color: | Beige |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 24 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09195245924 |
09195245924
Specifications
Detailed Description
The SEK Standard Male Connector ( 09195245924) offers reliable PCB to cable connectivity in electronic assemblies. Made of durable thermoplastic resin (PCT) in a sleek beige finish, this connector is designed for reflow soldering termination (THR/SMC) with a rated current of 1A. With 24 contacts arranged in 2 rows and a 2.54mm pitch, it provides secure and efficient signal transmission. Constructed with copper alloy contacts plated with tin over nickel and noble metal over nickel, it ensures excellent conductivity and corrosion resistance. Operating temperature ranging from -55°C to 125°C, along with a UL 94V-0 flammability rating, guarantees performance in various environmental conditions. With an IP20 rating for dust and moisture protection, this connector is ideal for a wide range of applications in the electronics industry.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
