| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09195646914 |
| Color: | Beige |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 64 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Straight |
| Tail Length: | 2.9 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09195646914 |
09195646914
Specifications
Detailed Description
The SEK Standard Connector, SKU 09195646914, offers reliable male-to-cable connection with its 64 contacts in 2 rows. Constructed with beige thermoplastic resin (PCT) housing and copper alloy contacts plated with tin over nickel, this connector ensures durability and efficient signal transmission. With a reflow soldering termination method, it is suitable for PCB applications. Operating within a wide temperature range of -55°C to 125°C, it guarantees performance in various environments. Its straight mount angle and 2.54mm pitch make it easy to install and compatible with standard PCB layouts. Rated for 1A current and 1kV voltage, it meets industry standards for safety and efficiency. With an IP20 rating and UL 94V-0 flammability rating, it ensures protection against dust, moisture, and fire hazards. Ideal for high-reliability applications, this connector is a dependable choice for demanding electronic systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
