09291306592

Introducing the DIN 41612 Type 3R Connector, a robust and reliable solution for your connectivity needs. This male connector, made from thermoplastic resin with glass-fibre filling, is designed for seamless integration in a variety of applications, from motherboard to daughtercard, mezzanine, and PCB to cable connections. In a sleek Pebble Gray color, this DIN 41612 series connector features 30 contacts in 3 rows, ensuring optimal signal transmission. With a solder termination method and copper alloy contacts plated with tin over nickel, gold over electroless nickel phosphorus over nickel, it guarantees secure and low-resistance connections. Operating efficiently in temperatures ranging from -55 to 125°C, with a pitch of 2.54mm and straight mount angle, this connector offers versatility in installation. With a tail length of 2.5mm and a high mating cycle rating of 400 cycles, it is built to withstand frequent use. Certified with a UL 94V-0 flammability rating and capable of handling 2A current and 1kV voltage, it ensures safety and performance. Perfect for high-reliability applications, this DIN 41612 Type 3R Connector ( 09291306592) is a must-have for your connectivity projects.
