| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09350026001 |
| Color: | Black |
| Pitch: | 2.4 mm, 3 mm |
| Gender: | Female |
| Series: | Han® PushPull (V14) |
| Mount Angle: | Right Angle |
| Mating Cycles: | 500 cycle |
| Current Rating: | 5 A |
| Voltage Rating: | 50 V |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Contacts: | 10 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT09350026001 |
09350026001
Specifications
Detailed Description
Han® PushPull Female Angled Connectors are essential for high-performance signal transmission in industrial settings. With a durable nylon housing and solder termination, these connectors ensure reliable conductivity in demanding environments. Featuring 10 copper alloy contacts with tin over nickel plating, they guarantee efficient power delivery with a current rating of 5A and a voltage rating of 50V. Designed for easy installation, the connectors have a 3mm pitch and a right-angle mount angle, perfect for space-constrained applications. With a temperature range from -40°C to 85°C and UL 94V-0 flammability rating, they are suitable for use in a wide range of operating conditions. These RoHS-compliant connectors, part of the Han® PushPull series, offer 500 mating cycles of dependable performance, making them an ideal choice for heavy-duty power connectivity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
