| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310314102000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Spring Cage |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 3.5 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 3 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 14 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 11 A |
| Voltage Rating: | 150 V |
| Conductor Size: | 30 - 14 AWG |
| SKU: | HRT14310314102000 |
14310314102000
Specifications
Detailed Description
The har-flexicon® Connector in Green is a reliable and efficient solution for horizontal PCB to cable connections. Featuring a push-in-spring-cage termination method, it ensures secure and easy installation. With a rated current of 11A and three contacts, it offers excellent performance. The connector is made of durable Nylon housing material with Copper Alloy contacts plated with Tin, guaranteeing long-lasting quality. Its wide operating temperature range from -40°C to 110°C makes it suitable for various environments. The 3.5mm pitch and straight mount angle accommodate different PCB layouts. UL 94V-0 rated for flammability, it meets high safety standards. Suitable for wire sizes ranging from 30 to 14 AWG, it offers versatility in connectivity. Whether for industrial or commercial applications, the har-flexicon® Connector is a dependable choice.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
