| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310314402000 |
| Pitch: | 3.5 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 14 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 14 AWG |
| Current Rating: | 10 A |
| Voltage Rating: | 150 V |
| Contact Plating: | Tin |
| Number of Poles: | 3 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Screw |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT14310314402000 |
14310314402000
Specifications
Detailed Description
Introducing the 14310314402000 har-flexicon® Connector, a versatile solution for horizontal PCB to cable connections. Featuring a durable Nylon housing in a vibrant green hue, this connector offers reliable screw termination and a high current rating of 10A. With three copper alloy contacts plated with tin, it ensures efficient conductivity while accommodating wire sizes ranging from 30 to 14 AWG. Designed for ease of use, it has a pitch of 3.5mm and a straight mount angle. Meeting UL 94V-0 flammability rating and RoHS compliance, it guarantees safety and environmental responsibility. Ideal for a range of applications, from industrial machinery to consumer electronics, the har-flexicon® Connector is a must-have component for any project.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
