| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310316102000 |
| Pitch: | 5 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 12 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 12 AWG |
| Current Rating: | 12 A |
| Voltage Rating: | 250 V |
| Contact Plating: | Tin |
| Number of Poles: | 3 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Spring Cage |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT14310316102000 |
14310316102000
Specifications
Detailed Description
Introducing the har-flexicon® Connector, a versatile and efficient solution for your PCB to cable connections. This horizontal connector features a push-in-spring-cage termination method, ensuring secure and reliable contact. With a rated current of 12A and 3 contacts, it is ideal for various applications. Constructed with durable PA/PPA housing material in a vibrant green color, it offers both performance and aesthetics. The copper alloy contacts with tin plating guarantee excellent conductivity. Operating temperature ranging from -40°C to 110°C and UL 94V-0 flammability rating ensure safety and reliability. With a pitch of 5mm, it accommodates wire sizes from 30 to 12 AWG. Whether for industrial machinery, automation systems, or electronic devices, the har-flexicon® Connector is the perfect choice for seamless connectivity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
