| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310317402000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Screw |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 5.08 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 3 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 15 A |
| Voltage Rating: | 250 V |
| Conductor Size: | 30 - 12 AWG |
| SKU: | HRT14310317402000 |
14310317402000
Specifications
Detailed Description
The har-flexicon® Connector in green features a horizontal design for easy PCB to cable connection with screw termination. With a rated current of 15A and three contacts, it ensures reliable power transmission. Constructed with durable Nylon housing and Copper Alloy contacts with Tin plating, it offers excellent conductivity and longevity. Operating temperature ranges from -40°C to 110°C, making it suitable for various environments. Its 5.08mm pitch and straight mount angle facilitate convenient installation. UL 94V-0 rated for safety, it accommodates wire sizes ranging from 30 to 12 AWG. Ideal for use in high-performance applications, this terminal block ensures secure and efficient connectivity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
