| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310616102000 |
| Pitch: | 5 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 12 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 12 AWG |
| Current Rating: | 12 A |
| Voltage Rating: | 250 V |
| Contact Plating: | Tin |
| Number of Poles: | 6 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Spring Cage |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT14310616102000 |
14310616102000
Specifications
Detailed Description
The har-flexicon® Connector 14310616102000 is a reliable and efficient solution for horizontal PCB to cable connections. Featuring a push-in-spring-cage termination method, this connector ensures secure and easy installation. With a rated current of 12A and 6 contacts, it offers high performance in various applications. Its housing, made of durable Nylon, in green color, ensures longevity and visibility. The copper alloy contacts with tin plating guarantee excellent conductivity. Operating temperature ranging from -40°C to 110°C, it is suitable for diverse environments. With a pitch of 5mm, it accommodates wire sizes from 30 to 12 AWG. UL 94V-0 rated for flammability, it meets safety standards. Ideal for PCB mount terminal block setups, this connector is a dependable choice for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
