14310715102000

HRT14310715102000
Heilind Number:HRT14310715102000
Manufacturer:HARTING
Manufacturer Number:14310715102000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Horizontal; PA / PPA, Green; PCB to cable; Push-in-spring-cage termination; Rated current: 11A; Contacts: 7

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14310715102000
Series:har-flexicon®
Housing Material:Nylo, Polyphthalamide
Termination Method:Spring Cage
Contact Material:Copper Alloy
Contact Plating:Tin Mating Side
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Pitch:3.81 mm
Insulation Material:Nylon, Polyphthalamide
Mount Angle:Straight
Number of Poles:7
Number of Levels:1
Housing Color:Green
Wire Size:30 to 14 AWG
Flammability Rating:UL 94V-0
Current Rating:11 A
Voltage Rating:150 V
Conductor Size:30 to 14 AWG
Operating Temperature:-40 to 110 °C
Mounting Angle:Straight
Part Aliases:
SKU:HRT14310715102000

Detailed Description

The har-flexicon® Connector in Green is a versatile and reliable solution for horizontal PCB to cable connections. Featuring a durable Nylon housing and copper alloy contacts with tin plating, this connector ensures excellent conductivity and longevity. With a push-in-spring-cage termination method, installation is quick and easy. Rated for 11A current and 150V voltage, it is suitable for a wide range of applications. The 3.81mm pitch and straight mount angle accommodate various PCB layouts. UL 94V-0 rated for flammability, it meets stringent safety standards. Compatible with wire sizes ranging from 30 to 14 AWG, it offers flexibility in design. Perfect for use in industrial, commercial, and residential electronics, the har-flexicon® Connector guarantees high performance and durability.
