| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310715402000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Screw |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 3.81 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 7 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 14 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 10 A |
| Voltage Rating: | 150 V |
| Conductor Size: | 30 - 14 AWG |
| SKU: | HRT14310715402000 |
14310715402000
Specifications
Detailed Description
Introducing the har-flexicon® Connector, a high-performance solution for horizontal PCB to cable connections. This durable connector features a green PA/PPA housing and screw termination for secure and reliable contact. With a rated current of 10A and 7 contacts, it is suitable for a wide range of applications. The connector is constructed with Nylon housing material and Copper Alloy contacts plated with Tin, ensuring long-lasting performance even in harsh environments. Operating temperature ranges from -40°C to 110°C, with a pitch of 3.81mm and wire size compatibility from 30 to 14 AWG. Meeting UL 94V-0 flammability rating standards, it guarantees safety and compliance. Trust the har-flexicon® Connector for efficient and durable connectivity in your PCB projects.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
