| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310814402000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Screw |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 3.5 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 8 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 14 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 10 A |
| Voltage Rating: | 150 V |
| Conductor Size: | 30 - 14 AWG |
| SKU: | HRT14310814402000 |
14310814402000
Specifications
Detailed Description
The har-flexicon® Connector in horizontal orientation offers reliable and efficient PCB to cable connectivity. Featuring a durable Nylon housing in a vibrant green color, this connector ensures secure termination with its screw method. With a rated current of 10A and 8 copper alloy contacts, it guarantees robust performance. Operating in temperatures ranging from -40°C to 110°C, it is suitable for various environments. Its pitch of 3.5mm and straight mount angle make it easy to install. RoHS compliant and UL 94V-0 rated for flammability, it meets high industry standards. Suitable for wire sizes ranging from 30 to 14 AWG, it is ideal for a wide range of applications in the industrial and electronic sectors.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
