14311015402000

HRT14311015402000
Heilind Number:HRT14311015402000
Manufacturer:HARTING
Manufacturer Number:14311015402000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Horizontal; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 10A; Contacts: 10

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311015402000
Series:har-flexicon®
Housing Material:Nylon
Termination Method:Screw
Contact Material:Copper Alloy
Contact Plating:Tin
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Pitch:3.81 mm
Insulation Material:Nylon
Mount Angle:Straight
Number of Poles:10
Number of Levels:1
Housing Color:Green
Wire Size:30 - 14 AWG
Flammability Rating:UL 94V-0
Current Rating:10 A
Voltage Rating:150 V
Conductor Size:30 - 14 AWG
Part Aliases:
SKU:HRT14311015402000

Detailed Description

Introducing the 14311015402000, a har-flexicon® Connector designed for horizontal PCB to cable applications. Featuring a durable Nylon housing in a vibrant green color, this connector ensures secure and reliable connections. With screw termination and copper alloy contacts plated with tin, it offers excellent conductivity and longevity. Rated for 10A current and 150V voltage, it is suitable for a wide range of electronic devices. With a pitch of 3.81mm and accommodating wire sizes from 30 to 14 AWG, it provides flexibility in installation. Meeting UL 94V-0 flammability standards, it guarantees safety in operation. Perfect for use in various industries, this connector is a dependable solution for your connectivity needs.
