| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14311017102000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Spring Cage |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 5.08 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 10 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 12 A |
| Voltage Rating: | 250 V |
| Conductor Size: | 30 - 12 AWG |
| SKU: | HRT14311017102000 |
14311017102000
Specifications
Detailed Description
Introducing the har-flexicon® Connector, the ideal solution for horizontal PCB to cable connections. This green connector features a durable PA/PPA housing and utilizes push-in-spring-cage termination for easy installation. With a rated current of 12A and 10 contacts, it ensures reliable power transmission. The housing is made of high-quality nylon, and the contacts are constructed from copper alloy with tin plating, guaranteeing excellent conductivity. Operating temperature ranges from -40°C to 110°C, making it suitable for a variety of environments. With a pitch of 5.08mm and straight mount angle, it offers versatility in installation. UL 94V-0 rated for flammability, it meets stringent safety standards. Suitable for wire sizes ranging from 30 to 12 AWG, this connector is a reliable choice for your PCB terminal block needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
