| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14311113101000 |
| Series: | har-flexicon® |
| Housing Material: | Liquid Crystal Polymer |
| Termination Method: | Spring Cage |
| Contact Material: | Copper Alloy, Spring Steel |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 2.54 mm |
| Insulation Material: | Liquid Crystal Polymer |
| Mount Angle: | Straight |
| Number of Poles: | 11 |
| Number of Levels: | 1 |
| Housing Color: | Black |
| Wire Size: | 26 - 20 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 6 A |
| Voltage Rating: | 160 V |
| Conductor Size: | 26 - 20 AWG |
| SKU: | HRT14311113101000 |
14311113101000
Specifications
Detailed Description
Introducing the har-flexicon® Vertical Connector, an essential component for seamless PCB to cable connections. With 11 contacts and a pitch of 2.54mm, this connector ensures reliable and efficient performance in your electronic assemblies. Featuring a durable black Liquid Crystal Polymer housing and Spring Cage termination, it offers secure connectivity in a wide range of environments. Rated for 6A current and 160V voltage, it meets stringent industry standards for safety and performance. RoHS compliant and UL 94V-0 rated for flammability, you can trust in its quality and reliability. Suitable for wire sizes 26-20 AWG, it is versatile and easy to install. Upgrade your terminal block setup with the har-flexicon® Vertical Connector.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
