| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14311114102000 |
| Series: | har-flexicon® |
| Housing Material: | Nylon |
| Termination Method: | Spring Cage |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 3.5 mm |
| Insulation Material: | Nylon |
| Mount Angle: | Straight |
| Number of Poles: | 11 |
| Number of Levels: | 1 |
| Housing Color: | Green |
| Wire Size: | 30 - 14 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 11 A |
| Voltage Rating: | 150 V |
| Conductor Size: | 30 - 14 AWG |
| SKU: | HRT14311114102000 |
14311114102000
Specifications
Detailed Description
Introducing the HAR-FLEXICON 11PIN FEMALE HO connector, the perfect solution for your high-performance electronic connections. Designed for reliability and ease of use, this connector features a durable Nylon housing and Spring Cage termination method. With Copper Alloy contacts plated in Tin, it ensures secure and efficient conductivity. Operating temperature ranges from -40 °C to 110 °C, making it suitable for a variety of environments. The 3.5mm pitch, straight mount angle, and 11 poles/1 level configuration offer versatility in connectivity. In a vibrant green housing, it not only stands out visually but also meets UL 94V-0 flammability standards for safety. Rated for 11A at 150V, with wire sizes accommodating 30-14 AWG, it's ideal for demanding applications. Trust in the HAR-FLEXICON for superior performance in your PCB mount terminal block setups.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
