14311115401000

HRT14311115401000
Heilind Number:HRT14311115401000
Manufacturer:HARTING
Manufacturer Number:14311115401000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Vertical; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 10A; Contacts: 11

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311115401000
Pitch:3.81 mm
Series:har-flexicon®
Wire Size:30 - 14 AWG
Mount Angle:Straight
Housing Color:Green
Conductor Size:30 - 14 AWG
Current Rating:10 A
Voltage Rating:150 V
Contact Plating:Tin
Number of Poles:11
Contact Material:Copper Alloy
Housing Material:Nylon
Number of Levels:1
Termination Method:Screw
Flammability Rating:UL 94V-0
Insulation Material:Nylon
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Part Aliases:
SKU:HRT14311115401000

Detailed Description

Introducing the har-flexicon® Connector, a vertical PA/PPA component in vibrant green, designed for efficient PCB to cable connections. Featuring screw termination for secure fastening, this connector boasts a high rated current of 10A and 11 contacts, ensuring reliable power and signal transmission. Constructed with durable Nylon housing and copper alloy contacts with tin plating, it offers excellent conductivity and longevity. With a pitch of 3.81mm, it is suitable for various applications. Operating seamlessly in temperatures ranging from -40°C to 110°C, and meeting UL 94V-0 flammability standards, it guarantees safety and performance. Accommodating wire sizes from 30 to 14 AWG, and rated for 150V, it is ideal for demanding environments. The har-flexicon® Connector is a essential component for any project requiring robust and efficient connectivity.
