14311117401000

HRT14311117401000
Heilind Number:HRT14311117401000
Manufacturer:HARTING
Manufacturer Number:14311117401000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Vertical; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 15A; Contacts: 11

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311117401000
Series:har-flexicon®
Housing Material:Nylon
Termination Method:Screw
Contact Material:Copper Alloy
Contact Plating:Tin
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Pitch:5.08 mm
Insulation Material:Nylon
Mount Angle:Straight
Number of Poles:11
Number of Levels:1
Housing Color:Green
Wire Size:30 - 12 AWG
Flammability Rating:UL 94V-0
Current Rating:15 A
Voltage Rating:250 V
Conductor Size:30 - 12 AWG
Part Aliases:
SKU:HRT14311117401000

Detailed Description

Introducing the har-flexicon® Connector, a versatile and reliable solution for your PCB to cable connections. This vertical connector features durable PA/PPA housing in a vibrant green color, ensuring both functionality and aesthetic appeal. With screw termination and a high-rated current of 15A, it guarantees secure and efficient power transmission. The 11 contacts, made of copper alloy with tin plating, offer optimal conductivity and longevity. Operating temperature ranges from -40°C to 110°C, making it suitable for various environments. UL 94V-0 flammability rating ensures safety compliance. Perfect for industrial and commercial applications, this connector accommodates wire sizes ranging from 30 to 12 AWG, catering to diverse needs. Trust in the har-flexicon® Connector for seamless and high-performance connectivity.
