| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14311216402000 |
| Pitch: | 5 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 12 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 12 AWG |
| Current Rating: | 15 A |
| Voltage Rating: | 250 V |
| Contact Plating: | Tin |
| Number of Poles: | 12 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Screw |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| Part Aliases: | |
| SKU: | HRT14311216402000 |
14311216402000
Specifications
Detailed Description
Introducing the har-flexicon® Connector, a reliable and efficient solution for your PCB to cable connections. This horizontal connector, featuring a durable Nylon housing in a vibrant green color, is designed for screw termination with a rated current of 15A. With 12 contacts, this connector ensures secure and stable connectivity. The contact material is made of Copper Alloy with a Tin plating, guaranteeing excellent conductivity. Operating at a maximum temperature of 110°C and a minimum temperature of -40°C, it offers versatility in various environments. The 5mm pitch and straight mount angle make installation easy and convenient. Suitable for wire sizes ranging from 30 to 12 AWG, this connector is UL 94V-0 rated for safety. Trust in the har-flexicon® Connector for high-quality performance in your electronic applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| HARTING: | 14311216402000 |
| Other Names: | |
