| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14311414402000 |
| Pitch: | 3.5 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 14 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 14 AWG |
| Current Rating: | 10 A |
| Voltage Rating: | 150 V |
| Contact Plating: | Tin |
| Number of Poles: | 14 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Screw |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT14311414402000 |
14311414402000
Specifications
Detailed Description
Introducing the HAR-FLEXICON 14PIN FEMALE HO Connector, a versatile and reliable solution for your connectivity needs. This connector, part of the har-flexicon® series, features a durable Nylon housing and Copper Alloy contacts with Tin plating for optimal performance. With a pitch of 3.5mm and straight mount angle, it's easy to integrate into your designs. Suitable for a wide range of applications, this connector has a maximum operating temperature of 110°C and is UL 94V-0 rated for flammability. It accommodates wire sizes ranging from 30 to 14 AWG and has a current rating of 10A at 150V. With RoHS compliance and high-quality construction, you can trust in the performance and reliability of the HAR-FLEXICON 14PIN FEMALE HO Connector. Upgrade your connectivity solutions today.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
