14311614402000

HRT14311614402000
Heilind Number:HRT14311614402000
Manufacturer:HARTING
Manufacturer Number:14311614402000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

HAR-FLEXICON, 16PIN FEMALE, HO

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311614402000
Series:har-flexicon®
Housing Material:Nylon
Termination Method:Screw
Contact Material:Copper Alloy
Contact Plating:Tin
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Pitch:3.5 mm
Insulation Material:Nylon
Mount Angle:Straight
Number of Poles:16
Number of Levels:1
Housing Color:Green
Wire Size:30 - 14 AWG
Flammability Rating:UL 94V-0
Current Rating:10 A
Voltage Rating:150 V
Conductor Size:30 - 14 AWG
Part Aliases:
SKU:HRT14311614402000

Detailed Description

Introducing the HAR-FLEXICON 16PIN FEMALE HO connector, part of the har-flexicon® series, designed for reliable and efficient PCB mounting. Featuring a durable Nylon housing in a vibrant green color, this connector ensures secure connections in a wide range of applications. With a screw termination method and copper alloy contacts plated with tin, it guarantees high conductivity and longevity. Operating smoothly in temperatures ranging from -40°C to 110°C, it is suitable for use in various environments. The 3.5mm pitch and straight mount angle make it easy to install, accommodating 16 poles on a single level. UL 94V-0 rated for flammability, with a current rating of 10A and voltage rating of 150V, it is a dependable choice for your connectivity needs. Supporting wire sizes from 30 to 14 AWG, it offers versatility and performance in demanding situations. Trust the HAR-FLEXICON connector for quality and durability in your projects.
