14311616402000

HRT14311616402000
Heilind Number:HRT14311616402000
Manufacturer:HARTING
Manufacturer Number:14311616402000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Horizontal; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 15A; Contacts: 16

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311616402000
Series:har-flexicon®
Housing Material:Nylon
Termination Method:Screw
Contact Material:Copper Alloy
Contact Plating:Tin
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Pitch:5 mm
Insulation Material:Nylon
Mount Angle:Straight
Number of Poles:16
Number of Levels:1
Housing Color:Green
Wire Size:30 - 12 AWG
Flammability Rating:UL 94V-0
Current Rating:15 A
Voltage Rating:250 V
Conductor Size:30 - 12 AWG
Part Aliases:
SKU:HRT14311616402000

Detailed Description

The har-flexicon® Connector 14311616402000 is a reliable and efficient solution for horizontal PCB to cable connections. With a durable Nylon housing in a vibrant green color, this connector offers secure screw termination for easy installation. Rated for a maximum current of 15A, it features 16 copper alloy contacts with tin plating, ensuring high conductivity and corrosion resistance. Operating temperature ranging from -40°C to 110°C, it is suitable for a wide range of environments. With a pitch of 5mm and straight mount angle, it allows for convenient PCB integration. UL 94V-0 rated for flammability, it guarantees safety in use. Accommodating wire sizes from 30 to 12 AWG, it meets the requirements of various applications. Ideal for use in industrial and commercial settings, the har-flexicon® Connector 14311616402000 is a dependable choice for your connectivity needs.
