| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 15110802601000 |
| Color: | Black |
| Pitch: | 1.27 mm |
| Gender: | Male |
| Series: | har-flex® |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Number of Rows: | 2 |
| Voltage Rating: | 0.5 kV |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Liquid Crystal Polymer |
| Number of Contacts: | 80 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT15110802601000 |
15110802601000
Specifications
Detailed Description
Introducing the har-flex® Connector, designed for seamless motherboard to daughtercard, mezzanine, and PCB to cable connections. This male connector features a robust housing made of Liquid Crystal Polymer, ensuring durability in various applications. With 80 contacts in 2 rows and a pitch of 1.27mm, it offers reliable connectivity. The reflow soldering termination method guarantees easy installation. Contacts plated with Tin over Nickel and Noble Metal over Nickel provide excellent conductivity. Operating in temperatures ranging from -55°C to 125°C, this connector is suitable for diverse environments. It meets UL 94V-0 flammability standards and is RoHS compliant, making it safe for use. Perfect for board-to-board and PCB connections, the har-flex® Connector is a dependable solution for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
