| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 15220122401000 |
| Color: | Black |
| Pitch: | 1.27 mm |
| Gender: | Female |
| Series: | har-flex® |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Number of Rows: | 2 |
| Voltage Rating: | 0.5 kV |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Liquid Crystal Polymer |
| Number of Contacts: | 12 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT15220122401000 |
15220122401000
Specifications
Detailed Description
Introducing the har-flex® Connector, a essential component for seamless motherboard to daughtercard or mezzanine connections. This female connector, featuring 12 contacts in a straight arrangement, is housed in durable black Liquid Crystal Polymer material for reliable performance. With a pitch of 1.27mm and solder termination method, it ensures secure and efficient connectivity. The copper alloy contacts are plated with Tin Over Nickel, Noble Metal Over Nickel for enhanced conductivity and longevity. Operating at temperatures ranging from -55°C to 125°C, this connector is suitable for a wide range of applications. Certified with UL 94V-0 flammability rating and a voltage rating of 0.5kV, it guarantees safety and quality. Perfect for use in board to board PCB connections, the har-flex® Connector is a must-have for any electronic assembly project.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
