| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 15220122601000 |
| Color: | Black |
| Series: | har-flex® |
| Gender: | Female |
| Housing Material: | Liquid Crystal Polymer |
| Number of Contacts: | 12 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 1.27 mm |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 2.4 - 3.3 A |
| Voltage Rating: | 0.5 kV |
| SKU: | HRT15220122601000 |
15220122601000
Specifications
Detailed Description
The har-flex® Connector ( 15220122601000) offers a reliable solution for connecting motherboards to daughter cards or mezzanine boards. Featuring a female LCP housing in sleek black, this connector is designed for reflow soldering termination with 12 straight contacts, making it ideal for high-density applications. With a pitch of 1.27mm and 2 rows of contacts, it ensures efficient signal transmission. Made of durable materials like Copper Alloy with Tin over Nickel and Noble Metal plating, it guarantees long-lasting performance even in harsh environments. With a wide operating temperature range of -55°C to 125°C, it is suitable for various industrial applications. RoHS compliant and UL 94V-0 rated for safety, this connector is a reliable choice for board-to-board connections.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
