G3VM-41LR6(TR05)

OMRG3VM-41LR6(TR05)
Heilind Number:OMRG3VM-41LR6(TR05)
Manufacturer:Omron Electric
Manufacturer Number:G3VM-41LR6(TR05)
ECAD Model:
3D Model

Description:

RELAY SSR SPST 120MA 4-SSOP

More >>

Specifications

AttributeValue
Product Category:
Solid State Relays & Components Solid State Relays
Manufacturer:Omron Electric
Manufacturer Part Number:Omron Electric G3VM-41LR6(TR05)
Series:G3VM
Mount Type:Surface Mount
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-20 °C
Contact Configuration:SPST-NO
Output Device:MOSFET
Contact Termination:Solder
Load Current:120 mA
Load Voltage:40 V
On-State Resistance:15 Ohm
SKU:OMRG3VM-41LR6(TR05)

Detailed Description

The G3VM-41LR6(TR05) is a high-performance solid-state relay that offers reliable switching capabilities for various electronic applications. Featuring a surface mount design for easy installation, this SPST-NO relay operates at a maximum load voltage of 40V and a load current of 120mA, making it suitable for low-power circuitry. With an on-state resistance of 15 Ohm, it ensures efficient power transfer while maintaining signal integrity. RoHS compliant, this relay is environmentally friendly and safe for use in any electronic system. The G3VM series is known for its quality and durability, providing long-lasting performance in industrial and commercial settings. Trust the G3VM-41LR6(TR05) for seamless relay operation in your next project.
