| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HP7-DE13322 |
| Series: | HP7 |
| Housing Material: | Aluminum |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP68S |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Exposed Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .361 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 10,000,000 Cycles |
| Mounting Style: | Panel Mount |
| Voltage Rating (DC): | 3 - 24 VDC |
| SKU: | OTTHP7-DE13322 |
HP7-DE13322
Specifications
Detailed Description
The HP7DE13322 is a high-performance Hall Effect momentary pushbutton switch designed for durability and reliability in demanding environments. Featuring a sealed aluminum housing with an IP68S rating, this switch is built to withstand harsh conditions. The black button with an exposed dome actuator provides a tactile and responsive interface. Ideal for panel mounting, it offers a secure connection with PC pin termination. With a voltage rating of 3-24VDC and an operating temperature range of -40°C to 85°C, it is suitable for a wide range of applications. The HP7DE13322 guarantees a long lifespan with a durability rating of 10,000,000 cycles, making it a dependable choice for industrial and commercial settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
