| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HP7-DE45325 |
| Series: | HP7 |
| Housing Material: | Aluminum |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP68S |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Exposed Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Wire Leads |
| Actuator Shape: | Round |
| Cap Color: | Green |
| Actuator Length: | .361 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 10,000,000 Cycles |
| Mounting Style: | Panel Mount |
| Voltage Rating (DC): | 3 - 24 VDC |
| SKU: | OTTHP7-DE45325 |
HP7-DE45325
Specifications
Detailed Description
The HP7DE45325 is a high-performance sealed pushbutton switch designed for durability and reliability in demanding environments. With an aluminum housing and IP68S rating, it ensures protection against dust and water ingress. The green button, made of thermoplastic, features a round exposed dome actuator for easy and responsive operation. Panel mountable with wire leads termination, this switch is suitable for various applications. Operating within a wide voltage range of 3-24VDC and a temperature range of -40°C to 85°C, it offers versatility and performance. With a durability rating of 10,000,000 cycles, the HP7DE45325 is a long-lasting solution for industrial, automotive, and aerospace systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
