| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HP7-DR13329 |
| Series: | HP7 |
| Housing Material: | Aluminum |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP68S |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | White |
| Actuator Length: | .385 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 10,000,000 Cycles |
| Mounting Style: | Panel Mount |
| Voltage Rating (DC): | 3 - 24 VDC |
| SKU: | OTTHP7-DR13329 |
HP7-DR13329
Specifications
Detailed Description
Introducing the HP7-DR13329, a high-performance Hall Effect Momentary Pushbutton Switch from the HP7 series. Featuring a sleek design with a White cap and Black case, this switch is not only visually appealing but also boasts an IP68S rating for superior durability. The Button (Raised Dome) actuator, made of Thermoplastic, offers a responsive and tactile feel. With a long lifespan of 10,000,000 cycles, it ensures reliable operation in demanding environments. Suitable for panel mounting with PC Pin termination, it guarantees easy installation. Operating at a voltage range of 3-24 VDC and with a temperature range from -40 °C to 85 °C, this switch is perfect for various applications. Upgrade to the HP7-DR13329 for seamless performance in your projects.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
