| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HP7-DR35223 |
| Series: | HP7 |
| Housing Material: | Aluminum |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP64 |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Wire Leads |
| Actuator Shape: | Round |
| Cap Color: | Orange |
| Actuator Length: | .385 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 10,000,000 Cycles |
| Mounting Style: | Panel Mount |
| Voltage Rating (DC): | 3 - 24 VDC |
| SKU: | OTTHP7-DR35223 |
HP7-DR35223
Specifications
Detailed Description
The HP7-DR35223, part of the HP7 series, is a high-performance Hall Effect Momentary Pushbutton Switch designed for durability and reliability in industrial environments. Featuring a rugged aluminum housing with a sleek black finish and an orange button for easy visibility, this switch is rated IP64 for protection against dust and water ingress. The button, made of durable thermoplastic, offers a tactile raised dome actuation. With a lifespan of 10,000,000 cycles, it ensures long-lasting functionality. Operating at voltages ranging from 3 to 24 VDC, and with a wide temperature range from -40°C to 85°C, it is suitable for a variety of applications. Ideal for panel mounting, it has wire lead terminations for easy installation. The HP7-DR35223 is the perfect choice for demanding industrial control systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
