| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HPL-3121121 |
| Series: | HPL |
| Housing Material: | Aluminum |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP65 |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised) |
| Case Color: | Silver |
| Actuator Material: | Thermoplastic |
| Termination Type: | Wire Leads |
| Actuator Shape: | Round |
| Cap Color: | Black |
| Actuator Length: | .25 in |
| Type: | Sealed |
| Durability Rating (Cycles): | 1,000,000 Cycles |
| Mounting Style: | Panel Mount |
| Voltage Rating (DC): | 5 VDC |
| SKU: | OTTHPL-3121121 |
HPL-3121121
Specifications
Detailed Description
The HPL-3121121 is a high-performance push button switch from the HPL series, designed for durability in demanding environments. With a sleek black cap and silver case, it offers a sophisticated aesthetic while meeting IP65 standards for dust and water resistance. Featuring a non-illuminated design and a tactile raised button actuator, it ensures reliable operation in industrial settings. The aluminum housing and thermoplastic actuator guarantee long-lasting performance, with a durability rating of 1,000,000 cycles. Suitable for panel mounting, it comes with wire leads for easy installation. Operating at a voltage rating of 5VDC and a temperature range of -40°C to 85°C, this sealed push button switch is ideal for a wide range of applications, from automotive to aerospace. Upgrade your control systems with the HPL3121121 and experience precision and reliability in every push.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
