LP5-A11J324

OTTLP5_A11J324
Heilind Number:OTTLP5-A11J324
Manufacturer:OTTO Controls
Manufacturer Number:LP5-A11J324
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Illuminated, Vandal Resistant, Aluminum, Alternate Action Pushbutton Switch

More >>

Specifications

AttributeValue
Product Category:
Switches Push Button Switches
Manufacturer:OTTO Controls
Manufacturer Part Number:OTTO Controls LP5-A11J324
Series:LP5-V
Cap Color:Black
IP Rating:IP6K8S
Case Color:Black
Illumination:Illuminated
Actuator Type:Button (Curved)
Actuator Shape:Round
Current Rating:5 A
Mounting Style:Panel Mount
Actuator Length:.13 in
Contact Plating:Silver
Switch Function:Off-On
Contact Material:Brass
Housing Material:Aluminum
Type:Sealed
Termination Type:Solder
Actuator Material:Aluminum
Durability Rating (Cycles):25,000 Cycles
Voltage Rating (AC):115 VAC
Voltage Rating (DC):28 VDC
Illumination Color:Amber
Illumination Voltage:12 V
Contact Configuration:SPST-NO
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-55 °C
SKU:OTTLP5-A11J324

Detailed Description

Introducing the LP5-V series Illuminated Vandal Resistant Aluminum Alternate Action Pushbutton Switch with SKU LP5-A11J324. Designed for durability with a 25,000 cycle lifespan, this black and silver switch features a round curved button actuator for comfortable use. The SPST-NO contact configuration and 5A current rating make it ideal for various applications, while the IP6K8S sealing ensures reliable performance in harsh environments. With an amber illumination color and 12V illumination voltage, this panel mount switch offers easy visibility. Crafted from high-quality aluminum and brass materials, it operates in a wide temperature range from -55°C to 85°C. Perfect for industrial and commercial settings, it guarantees long-lasting and efficient control.
