LP7-D5131G22

OTTLP7_D5131G22
Heilind Number:OTTLP7-D5131G22
Manufacturer:OTTO Controls
Manufacturer Number:LP7-D5131G22
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Illuminated Dome Pushbutton Switch

More >>

Specifications

AttributeValue
Product Category:
Switches Push Button Switches
Manufacturer:OTTO Controls
Manufacturer Part Number:OTTO Controls LP7-D5131G22
Series:LP7-D
Housing Material:Aluminum
Contact Material:Silver
Contact Plating:Gold
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-40 °C
IP Rating:IP6K4S
Illumination:Illuminated
Contact Configuration:SPDT
Actuator Type:Button (Raised Square Lightpipe)
Case Color:Black
Actuator Material:Thermoplastic
Termination Type:Solder
Actuator Shape:Square
Cap Color:Black
Actuator Length:.11 in
Switch Function:ON-ON
Type:Sealed
Durability Rating (Cycles):50,000 Cycles
Mounting Style:Panel Mount
Current Rating:5 A
Voltage Rating (AC):115 VAC
Voltage Rating (DC):28 VDC
Illumination Color:Green
Illumination Voltage:12 V
SKU:OTTLP7-D5131G22

Detailed Description

Introducing the LP7-D5131G22, a high-performance Illuminated Dome Pushbutton Switch designed for seamless operation in a variety of applications. This sleek and durable switch features a black button with a raised square lightpipe for easy actuation, making it perfect for panel mounting. Crafted with high-quality aluminum housing and thermoplastic actuator material, it ensures longevity even in demanding environments. The IP6K4S rating guarantees protection against dust and water ingress. With a green LED illumination and gold contact plating, this switch not only offers visual indication but also reliable conductivity. Its SPDT contact configuration and 5A current rating cater to diverse electrical setups. Operating flawlessly within a wide temperature range from -40°C to 85°C, this switch is suitable for industrial, automotive, and aerospace applications. Trust in the LP7-D5131G22 for dependable performance, meeting the highest standards of quality and durability.
