| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P2-111129 |
| Series: | P2 |
| Cap Color: | White |
| IP Rating: | Symbol 3 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .47 in |
| Contact Plating: | Silver |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 125 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | 2 SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP2-111129 |
P2-111129
Specifications
Detailed Description
Introducing the P2-111129 Push Button Switch from the P2 series. This high-performance switch features a sleek design with a white button cap and black housing. With an IP Rating of 3, it offers reliable protection against dust and water ingress. The button actuator, made of durable thermoplastic, provides a comfortable and responsive user experience. Ideal for panel mounting, this switch has a 5A current rating and a contact configuration of 2 SPST-NO, making it suitable for various applications. With a durability rating of 25,000 cycles and a wide operating temperature range from -55°C to 85°C, this switch ensures long-lasting performance even in harsh environments. Trust the P2-111129 for seamless and efficient control in your electronic devices.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
