| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P2-115524 |
| Series: | P2 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 3 |
| Illumination: | Not Illuminated |
| Contact Configuration: | 1 SPST-NC/1 SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Yellow |
| Actuator Length: | .47 in |
| Switch Function: | On-(Off) / Off-(On) |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 125 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP2-115524 |
P2-115524
Specifications
Detailed Description
Introducing the P2-115524 Push Button Switch, designed for reliable performance in demanding environments. With a durable thermoplastic actuator and sealed construction, this switch is ideal for industrial applications. The yellow button, set in a sleek black aluminum case, offers easy visibility and operation. Featuring a 25,000 cycle durability rating, it ensures long-lasting use. The switch's 1 SPST-NC/1 SPST-NO contact configuration and 5A current rating make it suitable for various circuit control tasks. With an IP rating of 3 and operating temperatures ranging from -55°C to 85°C, it guarantees functionality even in harsh conditions. Whether for panel mounting in machinery or equipment, this push button switch delivers quality and performance.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
